Backflow Assembly Test Report Form PDF Details

Ensuring the safety and functionality of a water system is paramount for both public health and environmental protection. The Backflow Assembly Test Report form serves as a crucial tool in this ongoing effort. Designed to meticulously document the condition and performance of backflow prevention assemblies, the form captures a wide array of essential information. From the basic details of the water system, such as its name, file number, and the assembly's location, to more specific data including the assembly's size, model, and serial numbers, every section is vital. Moreover, the report delves into the heart of the assembly's functionality, assessing components like the differential pressure, check valves, and relief valves, recording whether they closed tightly, leaked, or failed to open as required. The report doesn't stop at identifying issues; it also records any repairs undertaken, listing replaced parts like discs, springs, and diaphragms. Beyond detailing initial findings and interventions, the form concludes with results from a final test post-repair, indicating the assembly's overall performance. This exhaustive approach ensures that water systems are maintained under rigorous standards, safeguarding against potential backflow incidents that could compromise water quality. In essence, the Backflow Assembly Test Report form is more than just a document; it's a comprehensive record that promotes transparency, accountability, and, ultimately, public safety.

QuestionAnswer
Form NameBackflow Assembly Test Report Form
Form Length3 pages
Fillable?Yes
Fillable fields128
Avg. time to fill out15 sec
Other namesbackflow test form pdf, backflow test form, backflow test forms, backflow test sheet

How to Fill Out Backflow Prevention Assembly Test Report

Backflow Prevention Assembly Test Report at a glance

What it is: The Backflow Prevention Assembly Test Report is one report per assembly.

Who signs: Under Tester, write the Printed name, sign in Signature and write the Date. The Owner or owner's representative writes the Printed name, signs in Signature and writes the Date.

A filled-in Backflow Prevention Assembly Test Report example: an annual test of a reduced pressure assembly

Backflow Prevention Assembly Test Report example filled out, example: an annual test of a reduced pressure assembly
Alex Sample tests a reduced pressure assembly for an annual test report. The relief valve opened at 3.0 psid and line pressure was 60 psi on the initial test. The picture shows page 1, and every value in it is made up. Check valve 1 dropped 7.0 psid and every valve held tight. The assembly passed its initial test, so Final test stays empty in Reduced pressure principle assembly (RP). The type, service and reason are all listed choices, so Other stays empty in Assembly. Nothing goes in Repairs because no part was cleaned or replaced. Results and tester is left blank because it is on page 3.

How to fill out Backflow Prevention Assembly Test Report, box by box

Water supplier and premises

Backflow Prevention Assembly Test Report example filled out, water supplier and premises

Under 1. Water supplier and premises, enter the Water system or supplier, the Account or file number, the Owner of assembly and the Owner telephone.

Under Service address, enter the City, State and ZIP code, then the Location of assembly on the premises.

Assembly

Backflow Prevention Assembly Test Report example filled out, assembly

Under Assembly type, mark Reduced pressure principle (RP), Double check valve (DC), Pressure vacuum breaker (PVB), Spill resistant vacuum breaker (SVB) or Other.

Enter the Manufacturer, Model, Size, Serial number and Date installed (MM/DD/YYYY).

Under Service protected, mark Premises containment, Internal isolation, Fire line, Irrigation or Other.

Under Reason for test, mark New installation, Annual test, After repair, Relocated or Other.

Reduced pressure principle assembly (RP)

Backflow Prevention Assembly Test Report example filled out, reduced pressure principle assembly (RP)

Under 3. Reduced pressure principle assembly (RP), record in the Initial test and Final test: Relief valve opening point (psid), Relief valve did not open (yes or no) and Check valve 2 held tight or leaked.

Also record Check valve 1 pressure drop (psid), Check valve 1 held tight or leaked, Shutoff valve 2 held tight or leaked and Line pressure (psi).

Double check valve assembly (DC)

Backflow Prevention Assembly Test Report example filled out, double check valve assembly (DC)

Under 4. Double check valve assembly (DC), record in the Initial test and Final test: Check valve 1 pressure drop (psid), Check valve 1 held tight or leaked, Check valve 2 pressure drop (psid), Check valve 2 held tight or leaked and Shutoff valve 2 held tight or leaked.

Pressure or spill resistant vacuum breaker (PVB, SVB)

Backflow Prevention Assembly Test Report example filled out, pressure or spill resistant vacuum breaker (PVB, SVB)

Under 5. Pressure or spill resistant vacuum breaker (PVB, SVB), record in the Initial test and Final test: Air inlet opening point (psid), Air inlet opened fully (yes or no), Check valve pressure drop (psid) and Check valve held tight or leaked.

Repairs

Backflow Prevention Assembly Test Report example filled out, repairs

In the repairs table write C for cleaned or R for replaced.

Under 6. Repairs, Parts cleaned or replaced, mark each Part under Check valve 1, Check valve 2, Relief valve and Air inlet or PVB check.

The parts are Disc or rubber, Spring, Seat, Guide, Hinge pin, Diaphragm, O-rings, Relief valve module, Air inlet disc or spring and Other.

Enter the Description of repairs and parts used, Repaired by and Date repaired (MM/DD/YYYY).

Test gauge

Backflow Prevention Assembly Test Report example filled out, test gauge

Under 7. Test gauge, enter the Gauge manufacturer, Model, Serial number, Accuracy last verified (MM/DD/YYYY) and Verified by.

Results and tester

Backflow Prevention Assembly Test Report example filled out, results and tester

Under 8. Results and tester, mark the Initial test result as Passed or Failed and the Final test result as Passed, Failed or Not retested, then enter the Initial test date (MM/DD/YYYY) and Final test date (MM/DD/YYYY).

Enter the Tester, Tester certification number, Certification expires (MM/DD/YYYY), Testing company, Company telephone and Remarks.

By signing, you certify that the entries are complete and correct.

Under Tester, write the Printed name, sign in Signature and write the Date.

The Owner or owner's representative writes the Printed name, signs in Signature and writes the Date.

More rules for Backflow Prevention Assembly Test Report

Fill the test section for the assembly type tested and leave the others blank.

Record pressures in psid.
